The DSL147 is a high-performance, wide-angle, low-light lens with 4K resolution and F/1.4 aperture, designed for 1/3" and 1/2.8" HDR sensors. The all-glass construction makes it thermally stable and ideally-suited for indoor or outdoor applications in harsh environments.

Ultra-low F/# for superb low-light imaging in Automotive, Autonomous and Security related applications, 4K, Low-Ghost design provides excellent image quality.

• Hybrid lens for excellent image and distortion characteristics
• HDR-Optimized for Low flare and ghost
• High (4K) resolution and extremely low F/# for bright, sharp images.

DSL165 is a high-performance lens with ultra-low F/# for superior low light imaging in Automotive, Autonomous and Security applications. Low-Ghost HDR and 4K design provide excellent image quality. The all-glass construction makes it thermally stable and ideally-suited for indoor or outdoor applications in harsh environments.

The DSL213 is a miniature wide-angle and Day/Night lens designed for 1/3” format imagers with up to 2MP resolution. The Near Infrared correction and low F/# make this lens ideal for compact applications using active 850nm or 940nm light sources, and those used in low light situations.

NIR versions: No IR cut filter

DSL216 lens is a miniature, high-resolution SuperFisheyeTM lens designed to give a fisheye image with a horizontal field of view greater than 180 degrees on a 1/3” format sensor making it ideal for security or emerging applications like 360° cameras. Additionally, the DSL216 has an all-glass all-metal design which gives it thermal stability.

Key Features :

• Maximum field of view (FOV): 180°
• All glass design to optimize thermal stability
• F/2.0 for superior low-light performance

Applications :

• Security and Surveillance cameras
• Drone cameras
• Immersive Imaging cameras

Key Features :

• Wide field of view: 75°HFOV on 1/4” imager
• All glass elements provides environmental stability
• Distortion: f-θ type (image height is proportional to the input angle h = f*θ where f is the focal length)

Applications :

• Security and Surveillance

The DSL235 is a miniature wide angle lens designed for 2-3MP image sensors with 1/3” format. The DSL235 isoptimized for Day/Night applications with active illumination in the Near Infrared, which makes it ideal for space constrained applications utilizing 850nm or 940nm active illumination.

DSL322A-650-F2.0

Key Features :

• Miniature Wide Angle Day/Night Lens
• Compact design
• High image quality
• Wide angle design

Applications :

• Security / Surveillance
• Computer Vision

DSL355A-650-F2.8

Key Features :

• Miniature Wide Angle Lens
• Compact size
• High image quality
• Low distortion

Applications :

• Security / Surveillance
• Telecommunications / Video-Conferencing
• Action Cameras

The DSL401 is a miniature Tailored DistortionTM wide- angle lens designed for 4K+ HDR sensors with up to 1/2” format size. The compact size, low distortion and high image quality make this lens ideal for space constrained camera systems requiring minimal, if any, distortion correction in the ISP or software.

The DSL415 is a large-format, all-glass fisheye lens designed to give a full circular image on large format sensors such as 4/3” and certain 1” format sensors. The DSL415 will also provide a full HFOV of 195deg on most standard 1” imagers and full sensor coverage on [up to] 2/3” imagers.

Key Features :

• 195° Field of View
• Extremely High Resolution
• All-Glass Construction for Environmental Stability.
• F/2.4 for Excellent Low Light Performance

Applications :

• Security / Surveillance
• Broadcast cameras
• Immersive Imaging

DSL419B-650-F2.0

Key Features :

•  SuperFisheye FOV: 180°
•  All-Glass Design•  Good low light performance: F/2.0 aperture
•  Compact size

Applications :

• Security and Surveillance
• Drones
• Immersive Imaging
• Video Communication
• Consumer Devices and IoT
