Automotive There are 17 products.

Automotive
  • Available
    DSL180 1,3Mpx 1/4" 0,97 F/2,0

    The DSL180 lens is a Tailored DistortionTM, miniature SuperFisheyeTM lens designed with a field of view of up to 200 degrees on 1/5” to 1/2.8” format imagers with HD resolution. Special design techniques and hybrid design form are used to achieve increased magnification (angular resolution) off axis compared to a standard fisheye lens.  NIR versions: No IR cut filter

    The DSL180 lens is a Tailored DistortionTM, miniature SuperFisheyeTM lens designed with...

    The DSL180 lens is a Tailored DistortionTM, miniature SuperFisheyeTM lens designed with a field of view of up to 200 degrees on 1/5” to 1/2.8” format imagers with HD resolution....

    69,76 €

    Add to cart View
  • Available
    DSL181 1,3Mpx 1/3’’ 1,25 F/2,2

    The DSL181 lens is a miniature SuperFisheyeTM lens with Tailored DistortionTM designed with a field of view of up to 190 degrees on 1/4” to 1/2” format imagers with HD resolution. The low F-number, thermal stability, and special distortion characteristics make this lens ideal for exterior based camera applications.

    The DSL181 lens is a miniature SuperFisheyeTM lens with Tailored DistortionTM designed...

    The DSL181 lens is a miniature SuperFisheyeTM lens with Tailored DistortionTM designed with a field of view of up to 190 degrees on 1/4” to 1/2” format imagers with HD...

    69,76 €

    Add to cart View
  • Available
    DSL182 1,3M 1/2,7" 1,40 F/2,2

    Key Features :•  SuperFisheye FOV: 194°•  Tailored DistortionTM•  Superior low light performance: F/2.2 aperture•  Compact size Applications :•  Automotive Surround View•  Security and Surveillance•  Internet of Things (IoT)•  Computer Vision

    Key Features :•  SuperFisheye FOV: 194°•  Tailored DistortionTM•  Superior low light...

    Key Features :•  SuperFisheye FOV: 194°•  Tailored DistortionTM•  Superior low light performance: F/2.2 aperture•  Compact size Applications :•  Automotive Surround View•...

    69,76 €

    Add to cart View
  • Available
    DSL183 1,3Mpx 1/2,7" 1,30 F/2,3

    The DSL183 lens is a miniature SuperFisheyeTM lens with Tailored DistortionTM designed with a field of view of up to 181 degrees on 1/3.2” to 1/1.8” format imagers with HD resolution. The low F-number, thermal stability, and special distortion characteristics make this lens ideal for exterior based camera applications.

    The DSL183 lens is a miniature SuperFisheyeTM lens with Tailored DistortionTM...

    The DSL183 lens is a miniature SuperFisheyeTM lens with Tailored DistortionTM designed with a field of view of up to 181 degrees on 1/3.2” to 1/1.8” format imagers with HD...

    69,76 €

    Add to cart View
  • Available
    DSL184 1,3MP0 1/3" 1,40 F/2,0

    DSL184A-650F2.0Tailored DistortionTM Miniature SuperFisheyeTM Lens Key Features •  SuperFisheyeTM FOV: 180°•  Tailored DistortionTM•  Superior low light performance: F/2.0 aperture•  Compact size Applications :•  Automotive Surround View•  Security and Surveillance•  Internet of Things (IoT)•  Computer Vision

    DSL184A-650F2.0Tailored DistortionTM Miniature SuperFisheyeTM Lens...

    DSL184A-650F2.0Tailored DistortionTM Miniature SuperFisheyeTM Lens Key Features •  SuperFisheyeTM FOV: 180°•  Tailored DistortionTM•  Superior low light...

    69,76 €

    Add to cart View
  • Available
    DSL203A 2M 1/3,2" 2,80 F/2,6

    DSL203A Wide Angle Security Lens Key Features :• Designed for multi-megapixel resolution sensors• Full field of view of up to 140°• High brightness, F/2.6 aperture• All glass design provides environmental stability Applications :• Security and surveillance• Automotive rear view cameras

    DSL203A Wide Angle Security Lens Key Features :• Designed for multi-megapixel...

    DSL203A Wide Angle Security Lens Key Features :• Designed for multi-megapixel resolution sensors• Full field of view of up to 140°• High brightness, F/2.6 aperture• All glass...

    69,76 €

    Add to cart View
  • Available
    DSL208A 1/3" 15,80mm F/2,0 1,3Mpx

    DSL208 lens is a miniature glass lens optimized for HD imagers up to 1/3” format with HD resolution. This lens is Day/Night optimized and is near infrared corrected.  Available in NIR versions: No IR cut filter

    DSL208 lens is a miniature glass lens optimized for HD imagers up to 1/3” format with...

    DSL208 lens is a miniature glass lens optimized for HD imagers up to 1/3” format with HD resolution. This lens is Day/Night optimized and is near infrared corrected.  Available...

    69,76 €

    Add to cart View
  • Available
    DSL209A 1/4" 1,7mm F/2.0 1,3Mpx

    The DSL209 lens is a miniature wide-angle lens optimized for 1/4” format imagers with HD resolution. The wide field of view, low F-number, and f-θ distortion make this lens ideal for security and automotive applications.  Available in NIR versions: No IR cut filter

    The DSL209 lens is a miniature wide-angle lens optimized for 1/4” format imagers with...

    The DSL209 lens is a miniature wide-angle lens optimized for 1/4” format imagers with HD resolution. The wide field of view, low F-number, and f-θ distortion make this lens...

    69,76 €

    Add to cart View
  • Available
    DSL210D VGA 1/3" 2,20 F/2,0

    Key Features : • Wide field of view : 126 deg HFOV on 1/3” imager• Excellent low light performance: F/2.0 aperture• All glass elements providing environmental stability• Distortion: f-θ type (image height is proportional to the input angle h=f*θ where f is the focal length).

    Key Features : • Wide field of view : 126 deg HFOV on 1/3” imager• Excellent low light...

    Key Features : • Wide field of view : 126 deg HFOV on 1/3” imager• Excellent low light performance: F/2.0 aperture• All glass elements providing environmental stability•...

    69,76 €

    Add to cart View
  • Available
    DSL212D 1/3" 1,97mm F/3,0 1,3Mpx

    The DSL212 is a miniature wide-angle all-glass lens with Tailored Distortion. This lens was optimized for 1/3” format sensors with up to HD resolution. The Tailored Distortion wide field of view and all glass construction make it ideal for outdoor applications which depend on off axis angular resolution.  Available in NIR versions: No IR cut filter

    The DSL212 is a miniature wide-angle all-glass lens with Tailored Distortion. This lens...

    The DSL212 is a miniature wide-angle all-glass lens with Tailored Distortion. This lens was optimized for 1/3” format sensors with up to HD resolution. The Tailored Distortion...

    69,76 €

    Add to cart View
  • Available
    DSL215B 5M 1/4" 1,60 F/2,0

    Key Features :•  Low F/# for optimal low-light performance •  All glass elements provide environmental stability•  Cost effective construction Applications :•  Security/Surveillance Dome Cameras•  Automotive surround view

    Key Features :•  Low F/# for optimal low-light performance •  All glass elements...

    Key Features :•  Low F/# for optimal low-light performance •  All glass elements provide environmental stability•  Cost effective construction Applications :•...

    69,76 €

    Add to cart View
  • Available
    DSL216A 1/4" 1,30mm F/2,0 2-3Mpx

    DSL216 lens is a miniature, high-resolution SuperFisheyeTM lens designed to give a fisheye image with a horizontal field of view greater than 180 degrees on a 1/3” format sensor making it ideal for security or emerging applications like 360° cameras. Additionally, the DSL216 has an all-glass all-metal design which gives it thermal stability.

    DSL216 lens is a miniature, high-resolution SuperFisheyeTM lens designed to give a...

    DSL216 lens is a miniature, high-resolution SuperFisheyeTM lens designed to give a fisheye image with a horizontal field of view greater than 180 degrees on a 1/3” format sensor...

    140,93 €

    Add to cart View
  • Available
    DSL217 1/3" 1,30mm F/1,8 3-5Mpx

    DSL217C-670-F1.8 •  Maximum field of view (FOV): 185o •  F/1.8 aperture for low-light performance •  Hybrid glass-plastic design •  Suitable for megapixel resolution sensors

    DSL217C-670-F1.8 •  Maximum field of view (FOV): 185o •  F/1.8 aperture for low-light...

    DSL217C-670-F1.8 •  Maximum field of view (FOV): 185o •  F/1.8 aperture for low-light performance •  Hybrid glass-plastic design •  Suitable for megapixel resolution sensors

    140,93 €

    Add to cart View
  • Available
    DSL239 1/2" 1,83mm F/2,4 14M

    DSL239-650-F2.44K Miniature SuperFisheyeTM Lens  Key Features : • SuperFisheye FOV: 186°• Good low light perfomance : F/2.4 aperture• 27,00mm TTL Applications : • Security and Surveillance cameras•  Drone cameras•  Immersive Imaging cameras

    DSL239-650-F2.44K Miniature SuperFisheyeTM Lens  Key Features : • SuperFisheye FOV:...

    DSL239-650-F2.44K Miniature SuperFisheyeTM Lens  Key Features : • SuperFisheye FOV: 186°• Good low light perfomance : F/2.4 aperture• 27,00mm TTL Applications : • Security...

    140,93 €

    Add to cart View
  • Available
    DSL255 1/2" 1,5mm F/2.0 10Mpx

    The DSL255 is an all-glass, miniature SuperFisheyeTM lens designed for 4K sensors with up to 1/2” format size. The SuperFisheyeTM design provides a FOV of 190 ̊ at design image circle of 4.3mm. The low F-number, compact size and thermal stability make this lens ideal for security and other high-quality indoor/outdoor imaging applications.

    The DSL255 is an all-glass, miniature SuperFisheyeTM lens designed for 4K sensors with...

    The DSL255 is an all-glass, miniature SuperFisheyeTM lens designed for 4K sensors with up to 1/2” format size. The SuperFisheyeTM design provides a FOV of 190 ̊ at design image...

    140,93 €

    Add to cart View
