Lens DSL165A

The DSL212 is a miniature wide-angle all-glass lens with Tailored Distortion. This lens was optimized for 1/3” format sensors with up to HD resolution. The Tailored Distortion wide field of view and all glass construction make it ideal for outdoor applications which depend on off axis angular resolution.

Available in NIR versions: No IR cut filter

DSL315B-650-F2.3

Key Features :

4K Miniature SuperFisheye TM Lens
• 190-degree field of view
• Compatible with many common sensor formats/resolutions
• All glass elements provide environmental stability

Applications :

• Security / Surveillance
• VR / 360o cameras
• Computer Vision

The DSL977 is an all-glass lens designed for 1MP HDR imagers. Special optical design, coating and process techniques are applied to achieve the high resolution, low relative aperture eliminating lens ghosting (120dB) and minimize flare and stray light.

Key Features :

• NoGhost, low stray light for HDR sensors
• Low relative aperture F/1.8
• Face Sealed to IP6K9K
• Compact size

Le DSL660 est un objectif grand angle haute performance conçu pour offrir des performances exceptionnelles sur les capteurs >4K avec une distorsion extrêmement faible et est optimisé pour réduire les artefacts de lumière parasite.

The DSL945 is a 4K lens designed for 1/2.3” imagers with up to 10MP resolution. The high resolution of this lens makes it ideal for scanning and finite conjugate machine vision applications.

Key Features  :

•  Wide angle, low distortion
•  High performance compact design
•  Finite conjugate optimized

Applications :

•  Document scanning
•  Video-conferencing
•  Finite Imaging

Key Features :

•  SuperFisheye FOV: 194°
•  Tailored DistortionTM
•  Superior low light performance: F/2.2 aperture
•  Compact size

Applications :

•  Automotive Surround View
•  Security and Surveillance
•  Internet of Things (IoT)
•  Computer Vision

The DSL147 is a high-performance, wide-angle, low-light lens with 4K resolution and F/1.4 aperture, designed for 1/3" and 1/2.8" HDR sensors. The all-glass construction makes it thermally stable and ideally-suited for indoor or outdoor applications in harsh environments.

The DSL935 lens is a multiple element glass lens optimized for 1/1.8” format imagers with up to 5MP resolution. The small form factor makes this lens ideal for high performance handheld cameras.

DSL208 lens is a miniature glass lens optimized for HD imagers up to 1/3” format with HD resolution. This lens is Day/Night optimized and is near infrared corrected.

Available in NIR versions: No IR cut filter

Compatibility GoPro ® HERO 1, HERO 2, HERO 3, HERO 3+ and HERO 4 ®

The GoPro can finally be equipped with a telephoto lens with horizontal field of view 15°.

An image of high quality.

Following the latest optical generation, this lens will give exceptional performances.

Key Features:

•  Maximum field of view (FOV): 180o
•  All glass design to optimize thermal stability
•  F/2.0 for superior low-light performance

Application :

• Security/Surveillance
• Consumer imaging
• Automotive surround view

The DSL181 lens is a miniature SuperFisheyeTM lens with Tailored DistortionTM designed with a field of view of up to 190 degrees on 1/4” to 1/2” format imagers with HD resolution. The low F-number, thermal stability, and special distortion characteristics make this lens ideal for exterior based camera applications.
