Lens DSL355
DSL355A-650-F2.8
Key Features :
• Miniature Wide Angle Lens
• Compact size
• High image quality
• Low distortion
Applications :
• Security / Surveillance
• Telecommunications / Video-Conferencing
• Action Cameras
Data sheet
DSL355A-650-F2.8
Key Features :
• Miniature Wide Angle Lens
• Compact size
• High image quality
• Low distortion
Applications :
• Security / Surveillance
• Telecommunications / Video-Conferencing
• Action Cameras
The DSL934B is a multi-element glass lens optimized for 3-5MP imagers with up to 1/1.8” format size. The compact size and all-glass all-metal construction make this lens ideal for applications requiring high resolution and temperature stability such as discreet outdoor security cameras.
DSL419B-650-F2.0
Key Features :
• SuperFisheye FOV: 180°
• All-Glass Design• Good low light performance: F/2.0 aperture
• Compact size
Applications :
• Security and Surveillance
• Drones
• Immersive Imaging
• Video Communication
• Consumer Devices and IoT
Key Features :
• Wide field of view: 75°HFOV on 1/4” imager
• All glass elements provides environmental stability
• Distortion: f-θ type (image height is proportional to the input angle h = f*θ where f is the focal length)
Applications :
• Security and Surveillance
The DSL209 lens is a miniature wide-angle lens optimized for 1/4” format imagers with HD resolution. The wide field of view, low F-number, and f-θ distortion make this lens ideal for security and automotive applications.
Available in NIR versions: No IR cut filter
The DSL212 is a miniature wide-angle all-glass lens with Tailored Distortion. This lens was optimized for 1/3” format sensors with up to HD resolution. The Tailored Distortion wide field of view and all glass construction make it ideal for outdoor applications which depend on off axis angular resolution.
Available in NIR versions: No IR cut filter
Key Features :
• All glass construction to optimize thermal stability
• Low F/# for improved low light performance
• Compact size
Applications :
• Security and Surveillance
• Drone cameras
• Immersive Imaging
DSL311A 650F2.8
Key Features :
• 151° FOV
• F/2.8
• 22mm TTL
Applications:
• Security/Surveillance
• Automotive Rear-view
• Sports and Wearable Cameras
DSL208A-650-F4.0 lens is a miniature glass lens optimized for HD imagers up to 1/3” format with HD resolution. This lens is Day/Night optimized and is near infrared corrected.
Available in NIR versions: No IR cut filter
The DSL935 lens is a multiple element glass lens optimized for 1/1.8” format imagers with up to 5MP resolution. The small form factor makes this lens ideal for high performance handheld cameras.
Key Features :
• Tailored DistortionTM
• 4k+ resolution
• Compact Design
Applications :
• Video Conferencing
• Drones
• Security and Surveillance
• Consumer Devices and IoT
The DSL213 is a miniature wide-angle and Day/Night lens designed for 1/3” format imagers with up to 2MP resolution. The Near Infrared correction and low F/# make this lens ideal for compact applications using active 850nm or 940nm light sources, and those used in low light situations.
NIR versions: No IR cut filter
DSL165 is a high-performance lens with ultra-low F/# for superior low light imaging in Automotive, Autonomous and Security applications. Low-Ghost HDR and 4K design provide excellent image quality. The all-glass construction makes it thermally stable and ideally-suited for indoor or outdoor applications in harsh environments.
The DSL147 is a high-performance, wide-angle, low-light lens with 4K resolution and F/1.4 aperture, designed for 1/3" and 1/2.8" HDR sensors. The all-glass construction makes it thermally stable and ideally-suited for indoor or outdoor applications in harsh environments.
DSL203A Wide Angle Security Lens
Key Features :
• Designed for multi-megapixel resolution sensors
• Full field of view of up to 140°
• High brightness, F/2.6 aperture
• All glass design provides environmental stability
Applications :
• Security and surveillance
• Automotive rear view cameras
The DSL491 is an all-glass, high-resolution (4K+), wide- angle lens designed for HDR and/or 4K sensors up to 1/2”format size. The design provides a maximum FOV of 150 ̊ at maximum image circle of 8.0mm. The compactsize and thermal stability make this lens ideal for security and other high-quality indoor/outdoor imaging applications.
Compatible with the CMT 398
